MIL-DTL-2036 Enclosures For Electric And Electronic Equipment, Naval ShipboardThis specification covers requirements for enclosures that house electric and electronic equipment for Naval shipboard use. Details concerning construction, ventilation, cooling, and mechanical protection are included in this specification. This specification also covers that class of explosion proof equipment which will contain any spark or ignition within the enclosure and not permit ignition in the surrounding external atmosphere as a result of normal operation or failure of electrical circuits within the enclosure. This specification is not intended to cover enclosures which form an integral part of equipment such as batteries.

Pages 1 - - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 - 32|||

MIL-DTL-2036E

APPENDIX A

TYPICAL DRIVE SHAFT PENETRATIONS

NOTE: CHAMFERS ARE NOT PART OF JOINT WIDTH

DIMENSIONS FOR DRIVE SHAFT JOINTS

DIMENSIONS � INCHES

"C" MAXIMUM

MINIMUM WIDTH

SIZE OF ENCLOSURE

RADIAL CLEARANCE

OF JOINT

INTERNAL FREE

BALL AND

VOLUME, IN

SLEEVE

W1+W2

ROLLER

BEARINGS

W1+W2+W3

BEARINGS

SMALLER THAN 125

.75 (19.05)

.004 (.1016) .010 (.254)

1 (2.54)

.005 (.127)

.010 (.254)

UNRESTRICTED

1.5 (38.1)

.007 (.177) .012 (.3048)

SH 9251

FIGURE A-4. Drive shaft joints.
