MIL-DTL-2036E

APPENDIX A

NOTES: (1) CHAMFERS ARE NOT PART OF THE JOINT WIDTH

(2) Co MAY BE SPECIFIED AS EITHER RADIAL OR DIAMETRICAL CLEARANCE.

DIMENSIONS FOR STEPPED JOINTS

SIZE OF ENCLOSURE

DIMENSIONS OF JOINT � INCHES (mm)

MINIMUM

MAXIMUM

INTERNAL FREE

TOTAL WIDTH

WIDTH OF

CLEARANCE

DIAMETRICAL

VOLUME � IN

OF STEPPED RADIAL CLAMPED

OF RADIAL

CLEARANCE OF

JOINT

SECTION OF AXIAL SECTION

WT+WO

JOINT

LESS THAN 125

.5 (12.7)

.046875 (1.190625) .0015 (.0381)

.003 (.0762)

MOTORS ONLY

.5 (12.7)

.09375 (2.38125)

.002 (.0508)

.004 (.1016)

LESS THAN 125

.625 (15.875)

.125 (3.175)

.003 (.0762)

.004 (.1016)

.625 (15.875)

.25 (6.35)

.003 (.0762)

.008 (.2032)

UNRESTRICTED

.75 (19.05)

.125 (3.175)

.003 (.0762)

.004 (.1016)

.75 (19.05)

.25 (6.35)

.003 (.0762)

.008 (.2032)

1 (2.54)

.125 (3.175)

.004 (.1016)

1 (2.54)

.25 (6.35)

.004 (.1016)

.008 (.2032)

SH 9249

FIGURE A-2. Stepped joints.
