MIL-DTL-24308 Connectors, Electric, Rectangular, Nonenvironmental, Miniature, Polarized Shell, Rack And Panel, General Specification ForThis specification covers the requirements for nonenvironmental, polarized shell, miniature, rack and panel connectors having pin and socket, crimp \(removable\), solder \(nonremovable\), or insulation displacement \(nonremovable\) contacts with rigid or float mounting, designed for -55 degrees C to +125 degrees C operating temperature range.

Pages 1 - - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 - 32 - 33 - 34 - 35 - 36 - 37 - 38 - 39|||

MIL-DTL-24308G

APPENDIX A

ARRANGEMENT 1

25 size 20 contacts

ARRANGEMENT 2

44 size 22D contacts

Inches

.020

0.51

.155

3.94

.326

8.28

.489

12.42

.025

0.64

.160

4.06

.335

8.51

.515

13.08

.055

1.40

.163

4.14

.340

8.63

.520

13.21

.056

1.42

.200

5.08

.380

9.65

.544

13.82

.065

1.65

.205

5.21

.381

9.68

.560

14.22

.070

1.78

.218

5.54

.385

9.78

.565

14.35

.078

1.98

.245

6.22

.425

10.80

.598

15.19

.109

2.77

.250

6.35

.430

10.92

.605

15.37

.110

2.79

.272

6.91

.435

11.05

.610

15.49

.112

2.84

.290

7.37

.470

11.94

.650

16.51

.115

2.92

.295

7.49

.475

12.06

.652

16.56

.655

16.64

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for information only.

FIGURE A-3. Shell size 3.
