MIL-DTL-27599D
4.5.1.2 Critical inspection (group A inspection). The following dimensions and features shown on
the pertinent military standard are considered critical:
a.
Mating diameters J and W on figures 1 and 2 (maximum on plugs, minimum on receptacles).
b.
Key or keyway positions.
c.
Contact pattern relative to datum features.
d.
Registration of insert markings. (Hole pattern between the rear and the front face of the
insert.)
4.5.2 Group B inspection. Group B inspection shall consist of the inspections specified in table VI
in the order shown and shall be made on sample units which have been subjected to and have passed
the group A inspection. For group B inspection, the documentation and standard test conditions of
EIA-364 do not apply.
TABLE VI. Group B inspection.
Inspection
Requirement
Test
paragraph
paragraph
Visual and mechanical inspection 1/
Contact resistance 2/
Contact engagement and separating force 1/
Shell spring finger forces (plugs with spring fingers only) 1/ 3/
1/ The contractor may use in-process controls for this requirement.
2/ Test three contacts in each sample connector.
3/ Test five places. No failures permitted.
4.5.2.1 Sampling plan (group B inspection). A sample size shall be randomly selected in table VII. If
one or more defects are found the lot shall be rescreened and defects removed. A new sample in
accordance with table VII shall then be randomly selected. If one or more defects are found in the
second sample the lot shall be rejected and shall not be supplied to this specification.
TABLE VII. Sampling plans.
Lot size
Sample size
1 to 13
100 percent
14 to 150
13 units
151 to 280
20 units
281 to 500
29 units
501 to 1,200
34 units
1,201 to 3,200
42 units
16
