MIL-DTL-55235A
NOTES:
1. Major defect: A major defect is a defect, other than critical, that is likely to result in
failure, or to reduce materially the usability of the unit of product for its intended
purpose.
2. Minor defect: A minor defect is a defect that is not likely to reduce materially the
usability of the unit of product for its intended purpose, or is a departure from
established standards having little bearing on the effective use or operation of the unit.
4.5.2 Group B inspection. Group B inspection shall consist of the inspections specified in table III in
the order shown, and shall be made on sample units which have been subjected to and passed the
Group A inspection. Connectors having identical piece parts may be combined for lot purposes and shall
be in proportion to the quantity of each PIN numbered connector produced.
4.5.2.1 Group B sampling plan. A sample of parts shall be randomly selected in accordance with
table IIIa. If one or more defects are found, the lot shall be screened for that particular defect and defects
removed. After screening and removal of defects, a new sample of parts shall be randomly selected and
subjected to all tests in accordance with table IIIa. If one or more defects are found in the second
sample, the lot shall be rejected and shall not be supplied to this specification. Group B inspection shall
be performed in any order acceptable to the Government.
4.5.2.1.1 Disposition of sample units. Sample units which have passed all the Group B inspection
may be delivered on the contract or purchase order if the lot is accepted. Any connector deformed or
otherwise damaged during testing shall not be delivered on the contract or order.
TABLE III. Group B inspection.
Inspection
Requirement
Inspection
paragraph
paragraph
4.7.6
Coupling sleeve rotation
3.5
4.7.8
Form over
3.7
1/ Only those dimensions specified (see 3.1), shall be checked.
10
