MIL-DTL-83503C
TABLE II. Qualification inspection - Continued.
Requirement
Method
Inspection
paragraph
paragraph
Subgroup V (2 sample units)
Contact resistance 1/
Salt spray testing (corrosion) (unmated) 2/
Withstanding voltage (sea level)
Contact resistance 1/
Subgroup VI (2 sample units)
Contact retention (removable contacts)
a. Visual inspection for flaws or damage
Subgroup VII 4/
Fungus
a. Visual inspection
Withstanding voltage (sea level)
Subgroup VIII (Soldertail terminations only) (2 sample units)
Solderability 2/
Subgroup IX (flat cable connectors only) (4 sample units)
Cable retention 3/
4.6.6
Withstanding voltage (sea level)
Subgroup X (IDC flat cable connectors only) (2 sample units)
Connector-cable flexing
3.5.9
a. Visual inspection for flaws or damage
Withstanding voltage (sea level)
1/ If both contact resistance and low level circuit resistance are required, they shall be performed on
different contact positions. In no instance shall they be performed on the same positions.
2/ These samples shall not be subject to any test in any other group.
3/ Four samples selected at random.
4/ Test specimens may be from completely fabricated parts, or sections or subassemblies cut from
completely fabricated parts.
4.4.1.2.4 Production conditions. In the event that no production occurred during the reporting period, a
report shall be submitted certifying that the company still has the capabilities and facilities necessary to
produce the item. If during 2 consecutive reporting periods, there has been no production, the
manufacturer may be required, at the discretion of the qualifying activity, to submit the products to testing
in accordance with the qualifying inspection requirements.
TABLE III. Group A inspection.
Inspection
Requirement
Method
paragraph
paragraph
Visual and mechanical examination
Insulation resistance
Withstanding voltage (sea level)
13
