MIL-DTL-83503C
TABLE VI. Group C Inspection.
Inspection
Requirements
Method
paragraph
paragraph
Subgroup I (4 pair)
Low level contact resistance
Shock (specified pulse):
a. Visual inspection 10X magnification of solder joints and contacts for
cracks or other degradation)
Vibration:
a. Visual inspection for loosening of parts, cracks, or breaks.
b. No loss in continuity greater than 1 microsecond
Low level contact resistance
Subgroup II (2 pair)
Preconditioning
Mating and unmating forces
Durability
Contact resistance
Subgroup III (2 pair)
Temperature cycling:
a. Manually mate and unmate at low temps
b. After temp cycling visual inspection for degradation
Subgroup IV (2 pair)
Insulation resistance
Contact resistance
Temperature life
Insulation resistance
Contact resistance
Subgroup V (2 pair)
Withstanding voltage
Insulation resistance
Humidity:
a. Withstanding voltage (sea level)
(Immediately after humidity)
b. Insulation resistance
(Within 1 to 2 hours after humidity)
c. Insulation resistance
(24 hours after humidity)
d. Visual inspection for cracking or separation of the insulation.
Contact resistance
Subgroup VI (IDC flat cable connectors only) (4 sample units)
Withstanding voltage (sea level)
Connector-cable flexing
a. Visual inspection for flaws or damage
Withstanding voltage (sea level)
Subgroup VII (Soldertail terminations only) (2 sample units)
Solderability
15
