MIL-PRF-39012/18H
TABLE I. Dash numbers, cross-reference, and dimensions.
Part or Identifying
Inch (millimeters)
Applicable cable 2/
Dimensions
Number (PIN) 1/
maximum #
M17/
M39012/18-
Category A Field serviceable (no special tools required) 3/
X102
Cable group VI
(Superseding 0111 4/ )
60-RG142 5/
128-RG400 6/
X101
Cable group VII
(Superseding 0118 4/ )
110-RG302 5/ 6/ 7/
1.250 (31.75)
A
X103
Cable group IV
54-RG122 6/
X220
Cable group II
113-RG316 5/ 6/
X225
Cable group X
127-RG393 5/ 6/
Category C field replaceable (MIL-DTL-22520 crimp tool)
See note next to applicable cable for crimp die 3/ 8/
X013
Cable group VIA 9/
111-RG303 5/ 6/
A
1.500 (38.10)
X014
Cable group VIB 9/
60-RG142 5/
128-RG400 6/
