MIL-PRF-39012/18H
Ferrule
Crimp die or
Dash
A
B
Basic crimp
number
Positioner
number
tool 2/
± 0.003 ± 0.003
1/
M22520/5
-9
Closure A
X501
or
18-50
0.212
0.175
-5, -41
X502
Closure B
M22520/5-01
X503
18-51
0.250
0.220
-5, -11
Closure A
or
-19, -57
X504
18-52
0.245
0.206
Closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.001
0.03
.033
0.84
.145
3.68
.220
5.59
.002
0.05
.035
0.89
.175
4.45
.230
5.84
.003
0.08
.040
1.02
.183
4.65
.235
5.97
.005
0.13
.043
1.09
.206
5.23
.250
6.35
.015
0.38
.067
1.70
.210
5.33
.478
12.14
.017
0.43
.083
2.11
.212
5.38
.500
12.70
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 3. Contact and ferrule dimensions for category D only.
6
