MIL-PRF-39012/18H
Color
Color
Crimp
band
band
tensile,
A
Basic crimp
Crimp die or
Contact
+0.001
pounds
Dash no.
tool 2/
no. 1/
positioner
-0.002
min.
(N)
10 lbs.
Orn
X501
18-12
0.033
(44.28)
M22520/1-01
M22520/1-12
6 lbs.
Blue
X502
18-11
0.017
Green
(26.69)
20 lbs.
X503
Red
18-10
0.043
M22520/1-01
M22520/1-12
(88.96)
X504
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Contact material shall be copper beryllium. Connectors supplied with phosphor bronze
contacts are acceptable for Government use until existing stock is purged. This elimination
of the contact material option shall take effect 1 year from the date of this specification.
4. Crimp tensile test shall be in accordance with SAE-AS39029.
5. Copyright notice: All information disclosed in these specification sheets which is or may be copyright
is reproduced herein with the express permission of the copyright owner.
6. .003 inch maximum break.
7. Color bands shall be positioned so that no coloring material enters the inspection hole.
FIGURE 3. Contact and ferrule dimensions for category D only Continued.
