MIL-PRF-39012/18H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
Inch (millimeters)
PIN 1/
Applicable cable 2/
Dimensions
maximum #
M39012/18-
M17/
Category C field replaceable (MIL-DTL-22520 crimp tool)
See note next to applicable cable for crimp die 3/ 8/
X015
Cable group VIIA 10/
(Superseding X010 4/)
110-RG302 7/
X016
Cable group IV 11/
54-RG122 6/
1.500 (38.10)
A
X017
Cable group VIIB 10/
90-RG71 6/ 7/
X221
Cable group IIA 12/
113-RG316 5/ 6/
Category D Field replaceable Defined piece part 3/ 8/ 13/ 14/
X501
Cable group IV
54-RG122 6/
X502
Cable group V
1.234 (31.34)
A
95-RG180 5/ 6/ 7/
X503
Cable group VIB
60-RG142 5/
128-00001 6/
X504
Cable group VIA
111-RG303 5/ 6/
