MIL-PRF-39012/20H
RF high potential withstanding voltage:
Voltage and frequency: 1,000 volts rms at a frequency from 5 to 7.5 MHz.
Leakage current: Not applicable.
Cable retention force:
Noncrimp assemblies: 40 pounds (177.93 N), minimum.
Crimp assemblies:
50 pounds (222.41 N), minimum for cables .155 - .189 inch (3.94 mm 4.80 mm) OD.
60 pounds (266.90 N), minimum for cables .190 - .229 inch (4.83 mm 5.82 mm) OD.
75 pounds (333.62 N), minimum for cables .230 - .249 inch (5.84 mm 6.32 mm) OD.
90 pounds (400.34 N), minimum for cables .250 inch (6.35 mm) OD and larger.
Coupling mechanism retention force: 100 pounds (444.82 N), minimum.
RF leakage: -55 dB minimum, tested at a frequency between 2 and 3 GHz. This requirement may be
met by meeting the RF leakage requirement on the MIL-PRF-39012/16 connector which has the same
mating end design and which is intended for the same cable.
Insertion loss: .3 dB, maximum tested at 3 GHz.
PIN: M39012/20 (dash number from table I or "B" number from table III).
Group qualification: See table II.
TABLE II. Group qualification. 1/
Submission and qualification or 2/
Qualifies the following
Group
any of the following connectors
connectors
M39012/20
M39012/20
I
-X101
-X101
-X108
-X108
X102
II
BX002
BX002
BX003
BX003
III
-X006
-X006
-X007
-X007
-X010
-X010
IV
-X501
-X501
-X503
-X502
-X504
-X503
-X504
V
-X502
-X502
See notes at end of table.
11
