MIL-PRF-39012/20H
TABLE I. Dash numbers, cross-reference, and dimensions Continued.
PIN 1/
Applicable cable 2/
Inches (millimeters)
Dimensions
M39012/20-
M17/
maximum #
Category C Field replaceable (MIL-DTL-22520 crimp tool)
See note next to applicable cable group for crimp die 3/ 8/
X006
Cable group VIA 9/
111-RG303 5/ 6/
X007
Cable group VIB 9/
60-RG142 5/
128-RG400 6/
X011
Cable group VIIA 10/
(Superseding 0010 4/)
110-RG302 5/ 6/ 7/
2.000 (50.80)
A
X016
Cable group IV 11/
54-RG122 6/
X017
Cable group VIIB 10/
90-RG71 6/ 7/
X222
Cable group IIA 12/
113-RG316 5/ 6/
See notes at end of table.
3
