MIL-PRF-39012/20H
Crimp die
Ferrule
A
B
or
Dash
Basic crimp
number
± 0.003 ± 0.003
number
tool 2/
positioner
1/
M22520/5
05, 41
Closure B
X501
20-50
0.212
0.175
X502
or 9
Closure A
M22520/5-01
X503
20-51
0.250
0.220
5, 11, 57
Closure A or
X504
20-52
0.245
0.206
19 Closure B
1/ Contact numbers and ferrule numbers are for identification only.
2/ Class 2 tool may be used by OEM (see MIL-DTL-22520).
FIGURE 2. Contact and ferrule dimensions for category D only.
