MIL-PRF-39012/20H
TABLE II. Group qualification Continued. 1/
1/ If a connector manufacturer produces a connector which meets all the requirements for
two or more connector PIN's (within the same series), the manufacturer may receive
qualification approval for two or more connector PIN's qualifying the one connector.
It is not necessary that such connectors be in the same group. Each connector,
however, must be marked with its own appropriate PIN. For group qualification, the
connectors must be of similar design and be of the same materials and plating.
2/ For qualification retention, where more than one part is listed in a group in this
column, data may be supplied on any of those parts in order to retain qualification for
those parts in the corresponding right hand column. The part does not necessarily have
to be the part initially qualified.
TABLE III. Category B Non-field replaceable (special tools may be required).
Not for Air Force, Army, or Navy use. For OEM use only.
Inches
Applicable
PIN
(millimeters)
cable
Dimensions
1/ 2/ 3/
maximum #
M17/ 4/
M39012/20B0002
028-RG058*
A
2.000 (50.80)
M39012/20B0003
084-RB223*
1/ For cross-reference of PIN to superseded PIN or type designation, see table IV.
2/ For maintenance replacements for category B, see table V.
3/ Inactive for new design.
4/ The latest version of each cable shall be applicable.
# Dimensions are in inches. Metric equivalents are given for information only.
* Cable to be used when performing tests requiring cable.
