MIL-DTL-25516F
4.5.6 Qualification of additional cable sizes (class G and H). Qualification may be granted for additional
cable sizes provided those cable sizes have passed the tests in table VI in a different type configuration.
For additional cable sizes not previously tested, four mated connector samples shall be subjected to the
inspections specified in table VII.
TABLE VII. Qualification of additional cable sizes.
Inspection
Requirement
Test
paragraph
method
paragraph
4.7.1
3.1, 3.4, 3.5,
Visual and mechanical inspection 1/
3.7, 3.8
4.7.2
3.6.1
Insulation resistance
4.7.3
3.6.2
Dielectric withstanding voltage
4.7.10
3.6.9
Cable retention force (except classes H and Y)
4.7.11
3.6.10
Side load (except classes H and Y)
4.7.20
3.6.19
Corrosion resistance
4.7.23
3.6.22
Shielded clamp resistance (except classes H and Y)
1/ Marking will be considered defective only if it is illegible at the completion of the
required tests.
4.6 Conformance inspection.
4.6.1 Inspection of product for delivery. Inspection of product for delivery shall consist of group A
inspection.
4.6.1.1 Inspection lot. An inspection lot shall consist of all connectors of the same PIN produced under
essentially the same conditions, and offered for inspection at one time.
4.6.2 Group A inspection. Group A inspection shall consist of the inspections specified in table VIII in
the order shown.
4.6.2.1 Sampling plan (group A). Table VIII tests shall be performed on a production lot basis.
Samples shall be selected in accordance with table IX. If one or more defects are found, the lot shall be
screened for that particular defect and defective parts removed. A new sample of parts shall be selected
in accordance with table IX and all group A tests again performed. If one or more defects are found in the
second sample, the lot shall be rejected and shall not be supplied to this specification.
14
