MIL-DTL-25516F
TABLE VIII. Group A inspection.
Inspection
Requirement
Test method
paragraph
paragraph
4.7.1
Visual and mechanical inspection 1/
3.1, 3.4, 3.5,
3.7, 3.8
4.7.3
3.6.2
Dielectric withstanding voltage 2/
4.7.6
3.6.5
Contact engagement and separation force
4.7.12
3.6.11
Hermetic seal (except class G)
1/ Marking will be considered defective only if it is illegible at the completion
of the required inspections.
2/ Does not apply to connectors with all contacts and insulation unassembled.
TABLE IX. Inspection level.
Visual and mechanical inspection
Lot size
All
1 to 20
20
21 to 280
47
281 to 1,200
53
1,201 to 3,200
68
3,201 to 10,000
77
10,001 to 35,000
96
35,001 to 150,000
119
150,001 to 500,000
143
500,001 to over
4.6.3 Group B inspection. Group B inspection shall consist of the inspections specified in table X, in the
order shown. Sample units shall be selected from inspection lots that have passed group A inspection.
15
