INCH-POUND
MIL-PRF-39012/25F
3 March 2009
SUPERSEDING
MIL-C-39012/25E
23 July 1991
DETAIL SPECIFICATION SHEET
CONNECTORS, COAXIAL, RADIO FREQUENCY,
(HARDWARE FOR RADIO FREQUENCY COAXIAL CONNECTORS)
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-39012.
.921
REF.
ITEM 6
15°
ITEM 5
.343
FORM OVER
ALL AROUND
2
45°
45°
.730
.545
.781 MAX
± 30'
± 30'
±.002
±.002
.109
2.500
.012 ± .004
3.000
.125
.136
.144
SILVER SOLDER JOINT SHALL
WITHSTAND A TORQUE OF 20
IN-LBS. WITHOUT TURNING
ITEM 1
ITEM 3
ITEM 4
SAFETY CHAIN
OPTIONAL
(SEE NOTES 4 & 5)
OPTIONAL
3.60 ± .25 LONG FROM
CHAIN & RING
C OF RING TO CENTER OF
L
ATTACHMENT TO COVER
END
VIEW
.062
MAX
.760 ± .005
FIGURE 1. M39012/25-X001 cover for series C female connectors with bead chain.
M39012/25-X002 cover for series C female connectors with safety chain.
M39012/25-X101 cover for series C female connectors with wire rope.
