MIL-PRF-39012/25F
MARKING IN EITHER
LOCATION
ITEM 1
.365
.760 DIA.
MAX
A
A
ITEM 3
.535 DIA.
.595 DIA.
ITEM 2
.350
.310 ± .003
.879 REF.
REF.
.093 DIA 180° ± 30'
APART 2 STUDS
.093
BEAD CHAIN
(SEE NOTES 4 & 6)
.062 MAX
.144 DIA
STANDARD
OF HOLE
COUPLING
(SEE NOTE 4)
SECTION A-A
SAFETY CHAIN
OPTIONAL
(SEE NOTES 5 & 6)
SLEEVING
4.11 ± .25 LONG FROM
(SEE ITEM 5)
C OF RING TO CENTER
L
4.00 ± .25 LONG MEASURED
OF ATTACHMENT TO COVER
FROM CENTER OF RING
HOLE TO CENTER OF
ATTACHMENT TO COVER
WIRE ROPE
(SEE ITEM 4)
(SEE NOTE 8)
.760 ± .005 DIA.
OPTIONAL
.144 DIA OF
CHAIN & RING
HOLE
FIGURE 2. M39012/25-X003 cover for series C male connectors with bead chain.
M39012/25-X004 cover for series C male connectors with safety chain.
M39012/25-X103 cover for series C male connectors with wire rope.
3
