MIL-PRF-39012/25F
.827 DIA.
.455 MAX
MAX
.687 ± .005
.062 ± .005
DIA.
.062 ± .005
.062 ± .005
.632 ± .005
.312
MARKING
DIA.
(SEE NOTE 10)
OFFSET
COUPLING
(SEE NOTE 6)
ITEM 2
ITEM 3
ITEM 1
PEEN OVER
MEDIUM DIAMOND OR
CEMENT
STRAIGHT KNURL
.625-24 UNEF-2B
.144 DIA OF HOLE
BEAD CHAIN
2.50 ± .25
(SEE NOTES 4 & 8)
STANDARD COUPLING
(SEE NOTE 4)
SAFETY CHAIN
OPTIONAL
(SEE NOTES 7 & 8)
SLEEVING
4.00 ± .25 LONG
3.75 ± .25 LONG FROM
(SEE ITEM 5)
MEASURED FROM CENTER
C OF RING TO CENTER OF
L
OF RING HOLE TO CENTER OF
ATTACHMENT TO CAP
ATTACHMENT TO COVER
WIRE ROPE
(SEE ITEM 4)
(SEE NOTE 5)
.636 DIA
OPTIONAL
.032 REF.
.144 DIA OF HOLE
CHAIN & RING
FIGURE 7. M39012/25-X011 cap and chain for series N female connectors with bead chain.
M39012/25-X012 cap and chain for series N female connectors with safety chain.
M39012/25-X111 cap and chain for series N female connectors with wire rope.
11
