MIL-PRF-39012/25F
MARKING IN EITHER
LOCATION
.70 REF.
.152 ± .002
.020
FORM OVER
.468±.003
± .002
ALL AROUND
DIA (SEE NOTE 10)
ITEM 4
.047 ± .001 RAD
.124
4° ± 30'
MIN.
.593 DIA
+.005
.397
.385 -.000
MAX
± .002
2.25 ± .2
ITEM 3
ITEM 2
SEE DETAIL B
15° ± 30'
.094 ± .003
BEAD CHAIN
.047 ± .001
OFFSET
(SEE NOTES 4 & 5)
COUPLING
(SEE NOTE 6)
STD COUPLING
(SEE NOTE 4)
.144 DIA
OF HOLE
SAFETY CHAIN
OPTIONAL
(SEE NOTES 7 & 8)
SLEEVING
2.70 ± .25 LONG FROM
4.00 ± .25 LONG
(SEE ITEM 5)
C OF RING TO CENTER OF
L
MEASURED FROM CENTER
ATTACHMENT TO COVER
OF RING HOLE TO CENTER OF
ATTACHMENT TO COVER
(WIRE ROPE
SEE ITEM 6)
(SEE NOTE 5)
.515 DIA
OPTIONAL
.144 DIA OF
CHAIN & RING
HOLE
FIGURE 4. M39012/25-X006 cover for series BNC female connectors with bead chain.
M39012/25-X007 cover for series BNC female connectors with safety chain.
M39012/25-X106 cover for series BNC female connectors with wire rope.
