MIL-PRF-39012/25F
.69 REF.
.206 ± .002
.078 DIA 180° ± 30'
APART (2) STUDS
.593 DIA
(MARKING IN
MAX
EITHER LOCATION)
.436 -.004 DIA. .381 -.003 DIA
ITEM 2
.325 ± .25 REF
.320 ± .001 DIA
.331 ± .002
.032 ± .002
FLAT
ITEM 1
.281 DIA.
FORM OVER
ALL AROUND
BEAD CHAIN
OFFSET COUPLING
ASSEMBLY
END RING ASSEMBLY
(SEE NOTES 6 & 8)
(SEE NOTE 4)
SAFETY CHAIN
OPTIONAL
(SEE NOTES 7 & 8)
SLEEVING
4.00 ± .25 LONG
.325 ± .25 LONG FROM
(SEE ITEM 4)
MEASURED FROM CENTER
CENTER OF ATTACHMENT
OF RING HOLE TO CENTER OF
TO COVER
ATTACHMENT TO COVER
(WIRE ROPE
SEE ITEM 3)
(SEE NOTE 5)
.281 DIA
OPTIONAL
.144 DIA OF
CHAIN & RING
HOLE
FIGURE 5. M39012/25-X008 cover for series BNC male connectors with bead chain.
M39012/25-X009 cover for series BNC male connectors with safety chain.
8
