MIL-DTL-83505B
SOCKET
A
CIRCUIT BOARD
"B (SEE 3.1)"
HEMISPHERICAL TIP
WEIGHT GAUGE MAY BE EMPLOYED FOR
WITHDRAWAL FORCE TEST
Use gage
For acceptable
A dia (mm)
socket mating lead
dia
Max
Min
(mm)
+.0000
+.0002 (0.005)
-.0002 (0.005)
-.0000
.0210 (0.533)
.0160 (0.406)
.016 to .021 (0.41 to 0.53)
.0300 (0.762)
.0210 (0.533)
.021 - .030 (0.53 - 0.76)
.0400 (1.016)
.0300 (0.762)
.030 - .040 (0.76 - 1.02)
.0500 (1.270)
.0400 (1.016)
.040 - .050 (1.02 - 1.27)
.0190 (0.483)
.0170 (0.432)
.017 - .019 (0.43 - 0.48)
.0200 (0.508)
.0180 (0.457)
.018 - .020 (0.46 - 0.51)
.0330 (0.838)
.0300 (0.762)
.030 - .033 (0.76 - 0.84)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Material: Carbon steel, finish 16 microinches (0.41 µm) maximum.
FIGURE 5. Mating and unmating test gages.
11
