MIL-DTL-83513G
TABLE VII. Qualification and verification of qualification inspection - Continued.
1/
All sample units, except groups IV and V.
2/
Not required for retention of qualification.
3/
Preconditioning is not required.
4/
Cycling of connector three times is not required.
5/
Loose contacts only (see 4.5.2.1).
6/
Space class connectors only, Shell finish electroless nickel.
7/
Not required for verification of qualifications provided there are no changes in processes and
materials since last qualifications.
8/ Not required for group C inspections.
9/ Not required for connectors with printed circuit board (PCB) terminations.
10/ If applicable (see 3.6) samples may be taken from virgin samples or from other subgroups
(manufacturers discretion).
4.4 Conformance inspection.
4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist of groups A and
B inspections.
4.4.1.1 Inspection lot. An inspection lot shall consist of all connectors produced under essentially the
same conditions, and offered for inspection at one time.
4.4.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in table VIII,
in the order shown.
TABLE VIII. Group A inspection.
Inspection
Requirement
Test
paragraph
method
paragraph
Visual and mechanical inspection
Dielectric withstanding voltage (at sea level)
Insulation resistance
4.4.1.2.1 Sampling plan (group A). Table VIII tests shall be performed on a production lot basis.
Sample size shall be as specified in table IX. If one or more defects are found, the lot shall be screened
for that particular defect and defects removed. Alternatively, parts may be reworked and returned to the
lot where defects do not affect the form, fit, or function of the device, such as marking, residue, etc. Such
lots shall be clearly identified as reinspected. A new sample of parts shall be selected as specified in
table IX and all group A tests again performed. If one or more defects are found in the second sample,
the lot shall be rejected and shall not be supplied to this specification.
15
