MIL-DTL-83513G
TABLE IX. Lot and sample size.
Lot size
Visual and mechanical
examination
2 to 13
100%
14 to 150
13
151 to 280
20
281 to 500
29
501 to 1,200
34
1,201 to 3,200
42
3,201 to 10,000
50
10,001 to 35,000
60
35,001 to 150,000
74
150,001 to 500,000
90
500,001 and over
102
4.4.1.3 Group B inspection. Group B inspection shall consist of the inspections specified in table X
and shall be made on sample units randomly selected from inspection lots which have been subjected to
and have passed the group A inspection.
TABLE X. Group B inspection.
Inspection
Requirement
Test method
paragraph
paragraph
Contact resistance
Mating and unmating force
4.4.1.3.1 Sampling plan. Table X tests shall be performed on a production lot basis. Sample size shall
be as specified in table IX. If one or more defects are found, the lot shall be screened for that particular
defect and defects removed. Alternatively, parts may be reworked and returned to the lot where defects
do not affect the form, fit, or function of the device, such as marking, residue, etc. Such lots shall be
clearly identified as reinspected. After screening and removal of defects, a new sample of parts shall be
randomly selected and subjected to all tests in table X. If one or more defects are found in the second
sample the lot shall be rejected and shall not be supplied to this specification.
4.4.1.3.2 Disposition of sample units. Sample units, which have passed all of group B inspection, may
be delivered on the contract, if the lot is accepted.
4.4.2 Periodic inspection. Periodic inspection shall consist of group C inspection. Except where the
results of these inspections show noncompliance with the applicable requirements (see 4.4.2.1.4),
delivery of products which have passed groups A and B inspections shall not be delayed pending the
results of these inspections.
4.4.2.1 Group C inspection. Group C inspection shall consist of the inspections specified in table VII,
in the order shown. Group C inspection shall be made on sample units selected from inspection lots,
which have passed the groups A and B inspections.
16
