4.4.2.1.1 Sampling plan. Group C inspection shall be performed every 36 months on samples from
units produced during the period. Sampling shall be as specified in 4.3.1 except sample size shall be
specified in table XI and as follows: 2 each of class P and class M with type I contacts. If submitting
more than one shell finish sample size shall be 2 samples of class M (cadmium) and one sample class M
(nickel) with type I contacts. If submitting only one type of any class sample size shall be 2 samples of
each class. The connectors shall have their full complement of contacts. The samples shall be subjected
to the inspections of group I in table VII. The samples shall then be divided equally into two groups; one
shall be subjected to the group II inspections, and the other shall be subjected to the group III
inspections. The sample size used for the crimp tensile strength test of group IV shall be as specified in
4.3.1.2. Two additional type II samples shall be subjected to group V inspection only as specified in
TABLE XI. Qualification retention sampling plan.
Number of
Class
Type
Number of
samples 1/
connectors
M (cadmium)
I
2
4
M (cadmium)
II
1
2
M (nickel)
I
1
2
M (passivated stainless steel)
I
1
2
P
I
2
4
P
II
1
2
M or P
II 2/
2
4
PCB connector (cadmium) 2/
I
2
4
PCB (nickel) 3/
I
1
2
PCB (passivated stainless steel) 3/
I
1
2
1/ A sample consists of a mating plug and receptacle.
2/ For group V inspection only.
3/ Select from the following specification sheets MIL-DTL-83513/12 and MIL-DTL-83513/15 or
MIL-DTL-83513/18 and MIL-DTL-83513/21 or MIL-DTL-83513/24 and /27, or MIL-DTL-83513/30
and MIL-DTL-83513/33.
(These are 100 positions connectors and can be used to retain qualification for all other sizes of PCB
connectors.)
4.4.2.1.2 Failures. If one or more sample units fail to pass group C inspection, the samples shall be
considered to have failed.
4.4.2.1.3 Disposition of sample units. Sample units, which have been subjected to group C inspection,
shall not be delivered on the contract.
