MIL-DTL-83513G
TABLE VII. Qualification and verification of qualification inspection.
Inspection
Requirement paragraph
Test method paragraph
Group I (all sample units)
Visual and mechanical inspection 1/ 8/
Magnetic permeability 2/
Dielectric withstanding voltage 2/
At sea level 2/ 8/
At altitude 2/
Insulation resistance 8/
Contact resistance 8/
Contact engagement and separation forces
Mating and unmating force 8/
Temperature cycling 7
Humidity
7/
Dielectric withstanding voltage 7/
Insulation resistance 7/
Vibration
Shock
Durability
Contact resistance
Contact engagement and separation forces 3/
Mating and unmating forces 4/
Group II (one-half of sample units)
Salt spray (corrosion)
Low signal level contact resistance
Contact resistance
Mating and unmating force 4/
Contact retention 9/
Visual and mechanical inspection 1/
Group III (one-half of sample units)
Fluid immersion 7/
Mating and unmating force 7/ 4/
Insert retention (class M only)
Visual and mechanical inspection 1/
Group IV
Crimp tensile strength type I only 5/ 7/
Thermal vacuum outgassing (space application only) 6/ 7/
Group V (4 sample units, type II)
Solderability 7/
Resistance to soldering heat 7/
Contact retention 7/ 9/
Marking performance /10
