8 inch printed wiring boards, and for interconnections between printed wiring boards. The connectors are intended to provide a reliable connection between printed wiring and conventional wiring. The interconnector concept is intended to provide connection of printed wiring on one board to printed wiring on another board.

Pages 1 - - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28|||

MIL-DTL-21097G

Gage type

Size

Dim "A"

Dim "B"

Contact

�.0001

�.001

spacing

.0620

.042

.050

Nominal thickness

.0930

.055

.100

.1250

.088

.125 & larger

.0700

.1030

Maximum thickness

.1350

.0540

.0840

Minimum thickness

.1150

Inches

.0001

0.00

.055

1.40

.1030

2.62

.005

0.13

.0620

1.57

.1150

2.92

.010

0.25

.067

1.70

.1250

3.18

.0135

0.34

.0700

1.78

.1350

3.43

.015

0.38

.0840

2.13

.140

3.56

.042

1.07

.088

2.24

.375

9.53

.050

1.27

.0930

2.36

1.000

25.40

.0540

1.37

.100

2.54

NOTES:

1. Dimensions are in inches

2. Metric equivalents are given for information only.

FIGURE 3. Gages-types A and AD.
