4.6.6.1.2 Test II (see 3.10.1.2). The connector half which houses the receptacle contacts shall be supported and the
gage aligned with the individual contact. The forces to insert and separate that gage shall be measured and recorded.
The dimensions of the gage shall be as specified (see 3.1).
4.6.6.2 Total engagement force (see 3.10.2). Connectors shall be tested for total engagement force of the printed
circuit board. The engagement shall be accomplished in a manner similar to that which the connectors are subjected to
in service. The gage used shall be of maximum thickness as specified on figure 4.
Size
Dimension C
±.0001
.0700
2
.1030
3
.1350
4
"A" dimension for contact spacing
Size
.050
.100
.125
.156
06
.342 ±.003
.685 ±.005
.850 ±.010
1.070 ±.156
10
.542
1.085
1.350
1.694
12
.642
1.285
1.600
2.011
15
.742
1.585
1.975
2.475
18
.942
1.885
2.350
2.942
20
1.042
2.085
2.660
3.255
22
1.142
2.285
2.850
3.565
25
1.292
2.585
3.225
4.035
28
--
2.885
3.600
4.502
30
--
3.085
3.850
4.812
36
--
3.685
4.600
5.750
40
--
4.085
5.100
6.374
43
--
4.385
5.475
6.771
FIGURE 4. Edge connector mechanical gages.
