MIL-DTL-21097G
TABLE VIII. Qualification inspection Continued.
1/
Applicable to only types A and AD.
2/
Type CR as applicable.
3/
Applicable only to crimp and solder type CR contacts with wire sizes 22 and larger.
4/
Applicable only to Types A, AD, and CR.
5/
Connectors tested in this group shall not be subjected to the electrical response measurements specified
in the applicable requirements paragraph of these environments. The environments are being used for
conditioning of low level test samples.
TABLE IX. Qualification inspection for crimp contacts.
Inspection
Requirement
Test
paragraph
method
paragraph
Group 1 (50 samples)
Visual and mechanical inspection 1/
Crimp resistance
Salt spray
Current cycling (crimp)
Crimp resistance
Crimp tensile strength 2/
1/ Dimensional measurements are required on eight contacts only.
2/ Type CR, as applicable.
4.5 Conformance inspection.
4.5.1 Inspection of product for delivery. Inspection of product for delivery shall consist of group A inspection.
4.5.1.1 Inspection lot. An inspection lot shall consist of all the connectors and related contacts of the same style and
PIN, produced under essentially the same conditions, and offered for inspection at one time.
4.5.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in table X, in the order
shown.
4.5.1.2.1 Sampling plan (group A). Table X tests shall be performed on each production lot. Samples shall be
selected as specified in table XI. If one or more defects are found, the lot shall be screened for that particular defect
and defects removed. A new sample of parts shall be selected as specified in table XI and all group A tests again
performed. If one or more defects are found in the second sample, the lot shall be rejected and shall not be supplied to
this specification.
TABLE X. Group A inspection.
Inspection
Requirement
Test
paragraph
method
paragraph
Visual and mechanical inspection 1/
Engagement and separation forces
(board side)
Individual contact engagement
4.6.6.1
and separation forces
Test I 1/
Total engagement force 1/
Dielectric withstanding voltage
Bond strength, body assembly
1/ Applicable only to types A and AD.
15
