MIL-DTL-83502E
1/
TABLE II. First article inspection.
Inspection
Requirement
Method
paragraph
paragraph
Group I (10 samples)
Visual and mechanical
Mating force
Contact withdrawal force
Contact retention 2/
Insulation resistance
Withstanding voltage (sea level)
Contact resistance
Capacitance
Group II (2 sample units)
Vibration
Shock (specified pulse)
Durability
Insulation resistance
Group III (2 sample units)
Thermal shock
Insulation resistance
Humidity
Withstanding voltage (sea level)
Group IV (2 sample units)
Low level contact resistance
Corrosive atmosphere
Group V (2 sample units)
Solderability
Visual and mechanical inspection
Group VI (2 sample units)
Resistance to soldering heat
Visual and mechanical inspection
1/ Sockets with inserted terminals shall not be considered the same design as those
with the terminals molded in place.
2/ Not applicable to molded socket contacts.
4.5.3 Failures. One or more failures shall be cause for refusal to grant first article approval.
4.6 Disposition of first article samples. First article samples shall not be delivered on the contract.
