MIL-DTL-83502 Sockets, Plug-In Electronic Components, Round Style, General Specification ForThis specification covers round, plug-in electronic component sockets for use on panel boards, printed circuit boards, and microelectronic components \(see 6.1\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19

MIL-DTL-83502E

4.8.10 Vibration (see 3.13). Sockets shall be tested in accordance with test procedure EIA 364-28.

The following details shall apply:

a. Test condition - III.

b. Preparation - Mated with test plugs (see figure 2). See figure 5 for further details.

Following the test, contact resistance and contact withdrawal force shall be measured in

accordance with 4.8.8 and 4.8.4, respectively.

4.8.11 Shock (specified pulse) (see 3.14). The socket shall be tested in accordance with test procedure

EIA 364-27. The following details shall apply:

a. Mounting method and detection circuit - Mounted by normal means monitoring equipment used

shall be capable of detecting circuit interruptions greater than 1 microsecond.

b. Preparation - Mated with a test plug (see figure 2).

c. Test setup: See figure 5.

d. Acceleration requirements - Test condition G.

e. Number of blows - One blow in both directions along each of three mutually perpendicular axes for

a total of six shocks.

APPLICABLE TEST PLUG W ITH

LEADS MATED W ITH SOCKET

APPLY ONE LEAD OF DC POW ER

SUPPLY OR MONITORING EQUIPMENT

SOCKET UNDER TEST

SOCKET TO BE SECURED TO

RESPECTIVE SHOCK OR

VIBRATION FIXTURE

SOLDER JOINT OR W ELD TYP

CONNECTIONS CONTACTS W IRED

SERIES TO ESTABLISH SERIES CIRCUIT

APPLY ONE LEAD OF DC

POW ER SUPPLY OR

MONITORING EQUIPMENT

FIGURE 5. Vibration and shock test setup.
