MIL-DTL-83502E
ROUNDED PIN
DETAIL
A DIA
.100
(2.54) MIN
ENGAGEMENT
LENGTH
WEIGHT GAGE
MAY BE EMPLOYED FOR
HEMISPHERICAL TIP
WITHDRAWAL FORCE TEST
Contacts to accept
Max
A dia
mating leads
min
gage
Inches
mm
Inches
mm
0.43 +.08
Max
.0200 +.0000
0.501 +.000
-.03
-.0002
-.005
.017 +.003
-.001
Min
.0160 +.0002
0.406 +.005
-.0002
-.003
Max
.0350 +.0000
0.889 +.000
0.76 ±.13
-.0002
-.005
.030 ±.005
Min
.250 +.0020
.0635 +.051
-.0020
-.000
Max
.0450 +.0002
1.143 +.005
1.02 ±.13
-.0020
-.051
.040 ±.005
Min
.0350 +.0002
0.889 +.005
-.0000
-.000
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerance is ± .0005 inch (0.013 mm).
4. Material: All pins carbon steel, finish 4 microinch (0.10 μm) maximum.
FIGURE 3. Insertion and withdrawal gages.
13
