MIL-DTL-83502E
TABLE I. Materials.
Material
Specification
Paragraph
Beryllium copper
ASTM B139/B139M, ASTM B194,
or ASTM B196/B196M
Brass
ASTM B16/B16M
Diallyl phthalate
ASTM D5948
Fluxes
J-STD-004
Glass filled polyamide (nylon)
ASTM D4066
Gold
ASTM B488
Nickel
SAE-AMS-QQ-N-290
Polytetrafluoroethylene
ASTM D1710
Solder
J-STD-006
Tin-lead
SAE-AMS-P-81728
4.5 Sample size.
4.5.1 Group submission. For each specification sheet, ten samples shall be selected of the socket
having the largest number of contacts, which shall qualify sockets with a lesser number of contacts of the
same design, construction and materials. Two samples of each socket with the lesser number of contacts
shall be submitted to visual and mechanical inspection, dimensions and withstanding voltage. Alternate
terminal types specified by a single specification sheet may be qualified by submitting two samples of
each type of groups I and II in table II. When different termination finishes are being qualified
simultaneously sample sockets of each finish shall be selected so that there are equal, groups of each
finish. Where there is a low profile socket at the same design, to the same specification sheet, it may be
qualified at the same time by submitting two samples of the largest number of contacts to groups I and II
of table II.
4.5.2 Inspection routine. The sample shall be subjected to the inspections specified in table II, in the
order shown. All sample units shall be subjected to the inspections of group I. The sample shall be
divided into five groups of two units each and subjected to the inspections for their particular group.
9
